Standard Kitchen Base Cabinet Dimensions
By Kevin Sorby | Kitchen Designer & Cabinetmaker
Standard kitchen base cabinets typically feature a height of 720 mm and a depth of 560 mm (excluding doors). The table below provides a breakdown of common widths and recommended door quantities.
Base Cabinet Dimensions Table
In standard cabinetry, base cabinet widths are generally produced in 50 mm increments, reaching a practical maximum of 1200 mm. The following table provides a breakdown of common base cabinet widths and the standard door quantities used for each.
Please note that all depth dimensions refer strictly to the carcass. Door thickness is not included in these measurements.
| Cabinet Width | Height | Depth | Door Qty |
| 150 mm to 550 mm | 720 mm | 560 mm | 1 Door |
| 600 mm | 720 mm | 560 mm | 1 or 2 Doors |
| 650 mm to 1200 mm | 720 mm | 560 mm | 2 Doors |
The cabinet height does not include the kickboard height. Floor cabinet depth ideally should not exceed 600 mm (handles excluded).
Hinge Loading and Door Width
The reason for a maximum door width for a base cabinet being 600 mm is due to the door weight loading on the door hinges. If the door was any wider, the doors hinges would tend to sag under the weight.
You can overcome this extra weight by putting two hinges at the top of the door (one hinge under the other) and one hinge at the bottom of the door.
Note on measurements: All dimensions provided are based on standard industry practices, including guidelines established in the HIA Guide to Kitchen & Bathroom Construction.
